Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine

    Buy cheap Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine from wholesalers

    Buy cheap Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine from wholesalers
    • Buy cheap Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine from wholesalers

    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine

    Ask Lasest Price
    Brand Name : Reliable Plastic Bottle Blowing Machine
    Model Number : RM-9B Plastic Bottle Blowing Machine
    Certification : CE ISO SGS
    Supply Ability : 15 Set/Sets per Month For Plastic Bottle Blowing Machine
    Price : US $9,800-13,500 / Sets
    • Product Details
    • Company Profile

    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine

    Product Description

    Description--Plastic Bottle Blowing Machine

    Plastic Bottle Blowing Machine is suitable for producing PET plastic containers and bottles. It is widely used to produce the carbonated bottle ,mineral water,carbonated drink bottle, pesticide bottle oil bottle cosmetics,wide-mouth bottle etc.
    Adopting double crank to adjust mould ,heavy locking mould, stable and fast ,Adopt infrared oven to heat the perform ,the perform rotated and heated equally.
    The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow .It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.
    The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
    The machine can be operated in the step-by-step mode and the semi-auto mode.
    The machine is small with low investment, easy and safe to operate .


    Function--Plastic Bottle Blowing Machine

    1. Controlled by MITSUBISHI touch screen computer. Operate consistently and simply.
    2. Pneumatic elements from FESTO (German) and SMC (Japan)
    3. Energy-saving and environmentally friendly design. Mechanical units are compact and rational.
    4. Malfunction alert and diagnostic units allow easy maintenance.
    5. Suitable for manufacturing a variety of PET bottles: mineral water bottles, edible oil bottles, soda bottles, medicine bottle, cosmetics bottles etc..
    6. Oven can be made according the different preform requirements of customers


    Parameters--Plastic Bottle Blowing Machine




    Container
    Product material
    PET
    Volume
    0.1L-2L
    Theoretical output
    1200-1600PCS/H
    Preform length
    15mm-350mm
    Preform inner diameter
    φ5mm-38mm



    Moulding
    Max.mould plate Dimenstion(L x W)
    350x380mm
    Max.mould thickness
    180mm
    Clamping force
    45KN
    Mould opening stroke
    160mm



    Machine size and weight
    Main machine (L x W x H)
    160x60x161KM
    Main machine weight
    500Kg
    Heater (L x W x H)
    187x63x145KM
    Heater weight
    250Kg
    Power
    17.5kw
    Detailed Images
    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine
    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine
    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine
    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine
    Our Service

    Plastic Bottle Blowing Machine

    The sample service
    1.we can send you the video of the running machine.
    2.you are always welcome to come to visit our factory, and you may see the operation of the machines here . We will make the arrangement to pick you up when you come .
    3.If we get the permission of the customer who has brought the machines from us ,we can tell you their contact information, you can go to visit their factory.
    Customized service
    1.we can design the machines according your requirements(material ,power,filling type,the kinds of the bottles, and so on).
    2.at the same time we will give you our professional suggestion .
    After-sales service
    1.we will provide the bill of load on time to make sure you can get the machine quickly
    2.when you finish the Preparation conditions ,our engineer will go to your factory for the installation, testing and also training .
    3.we provide one year warranty with spare parts free.

    Packing & Delivery

    Plastic Bottle Blowing Machine

    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine
    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine
    Our Company

    Plastic Bottle Blowing Machine

    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine
    ---OUR CLIENTS---
    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine

    ---OUR WORKSHOP---

    Low Price PLastic PET Bottle Blowing Equipment / Blow Moulding Machine
