PET Preform Injection Molding Machine / Plastic Making Machine
PriceParameter
Item | Unit | Data |
Max. clamping force | KN | 2400 |
Max. opening force | mm | 530 |
(V×H)Space between tie bars | mm | 555×555 |
(min-max) Mould height | mm | 200-570 |
Max. daylight | mm | 1100 |
Ejector force | KN | 61.5 |
Ejector stroke | mm | 135 |
Ejector quantity | | 9 |
Screw diameter | mm | 55 | 60 | 65 |
Screw L/D ratio | L/D | 22.9 | 21 | 19.4 |
Theoretical shot volume | cm3 | 665 | 791 | 929 |
Plasticising weight(PS) | g | 605 | 720 | 845 |
Injection pressure | Mpa | 210 | 176 | 150 |
Theoretical injection rate(PS) | g | 176.5 | 210 | 245 |
Plasticising capacity(PS) | g/s | 26.4 | 32.5 | 40 |
Screw torque | N.m | 2000 |
Max. screw rotate speed | r/min | 150 |
Injection stroke | mm | 280 |
Pump motor power | KW | 22 |
Pump pressure | Mpa | 16 |
Heating power | KW | 18.5 |
Heating zone | | 5 |
Size | m | 6.2×1.6×2.1 |
Net weight | t | 8.0 |
International designation | | 2400-1390 |
PET Preform Injection Molding Machine / Plastic Making Machine
Price
Description---- PET Preform Injection Molding Machine
1) LCD computer control with big display screen for Injection
Moulding Machine
2) Hydraulic double proportional valve for Injection Moulding
Machine
3) Hard chrome plated high tensile strength steel tie bars for
Injection Moulding Machine
4) Generous space for fitting large moulds for Injection Moulding
Machine
5) Large opening stroke for Injection Moulding Machine
6) Two position transducers to control Clamping and Injection for
Injection Moulding Machine
7) Four stages of injecting, independent velocity and pressure
control for Injection Moulding Machine
8) Hydraulic mould height adjustment device for Injection Moulding
Machine
9) Screw cold-start prevention device for Injection Moulding
Machine
10) Melt decompression control for Injection Moulding Machine
11) Screw back pressure control for Injection Moulding Machine
12) Multiple hydraulic ejection for Injection Moulding Machine
13) Differential high speed clamping for Injection Moulding Machine
14) Centralized lubrication system for Injection Moulding Machine
15) Low pressure mould protection device for Injection Moulding
Machine
16) Mechanical safety interlock for Injection Moulding Machine
17) Double electrical safety interlock for Injection Moulding
Machine
18) Oil return filter for Injection Moulding Machine
19) Oil tank with inner stainless steel container for Injection
Moulding Machine
PET Preform Injection Molding Machine / Plastic Making Machine
Price
About Us
Our advantages
1)Our products with high stable excellent quality.
2)Comprehensive and creative product designs that not only match
the needs of customers
but also new market opening.Our products could be customized
according to customers’ requirements.
3)We have a professional experienced R & D team and
a highly reliable technical team offering quality and efficient
service to the users.
4)We have professional QC team that could guarantee stable quality
for OEM production service.
5)We try to guarantee competitive price with quality products for
customers all over the world.
Reliable Service
1) Any inquiries will be replied within 12 hours.
2) Quality of products will be strictly checked and every machine
will be test to confirm whether it works well before packing.
3) All the machines have 1 year warranty and life time maintenance.
4) We have professional engineers , after-sales staff and a
high-quality sales team to service you.
5) We have a sales team who are good at English to ensure zero
communication barriers.
