Dehumidification Drying Feed Three-In-One Monoblock Auxiliary
Equipment
SPMD 3 IN 1 DEHUMIDIFYING DRYERS
- The compact designed SPMD series 3-in-1 dehumidifying dryer ensures
the material are dried in the close-loop system , prevent external
air contact and perform drying effective.
- Microprocessor P.I.D control with overheating protection. Motor
overload ,phase reversal and timer delay cooling protection .
- PLC touch screen control with available (option) display
operational condition, trouble shooting and maintenance
instruction.
- -40℃ Dew-point ensure material completely dried.
- Bottom air flow release designed to prevent heat loss and increased
drying efficiency.
- Double insulation hopper prevents heat loss and maintain regular
temperature.
- Advanced technology, safety,reliable, small footprint and high
performance.
Dehumidification Drying Feed Three-In-One Monoblock Auxiliary
Equipment
SPECIFICATIONS
| Model | SPMD-
90L/80A | SPMD-
120L/80A | SPMD-
160L/120A | SPMD-
230L/160A | SPMD-
300L/220A | SPMD-
450L/300A | SPMD-
750L/400A | SPMD-
900L/500A |
Mateial Hopper | (L) Capacity | 90 | 120 | 160 | 230 | 300 | 450 | 750 | 900 |
Heat protection material | Fiberglass |
Dry-Air Dew point | -40℃ |
Temperature(℃) | 80-160 |
Air Flow(m3/h) | 80 | 130 | 160 | 220 | 300 | 400 | 500 |
Blower power(Kw) | 0.75 | 1.1 | 1.5 | 2.2 | 3 | 5.5 | 7.5 |
Regenerative blower(Kw) | 0.25 | 0.55 | 0.75 | 2.2 |
Heater Power(kw) | 3.9 | 6 | 6 | 7.2 | 12 | 15 | 18 | 21 |
Regenerative heat(Kw) | 3.9 | 5.4 | 7.2 | 10 |
Pipe Size | Drying(mm) | 51 | 63 | 76 | 100 |
Cooling(inch) | 3/4’’ |
Regeneration(mm) | 38 | 51 | 63 |
Conveying Blower(Kw) | 1.1 | 1.5 | 2.2 | 3.7 |
Conveying Distance(m) | Stage 1 | 10 |
Stage 2 | 10 |
| Hose Size(inch) | 1.5 | 2 |
Sensor Hopper Capacity(L) | 6 | 12 |
Vaccum Hopper Capacity(L) | 6 | 12 |
Dimensions(cm) | 180*100*87 | 225*165*125 | 225*165*130 | 280*150*130 | 286*178*130 | 316*214*138 |
Weight(Kg) | 310 | 340 | 360 | 420 | 550 | 600 | 750 | 830 |
Why our machine is better than other similar machines?
a. Small profits and quick returns is our business policy, so the
water bottling line is worth every cent.
b. We focus on advanced supply chain management, which can ensure
the raw materials are with
good quality and competitive price.
c. Workers, engineers and boss of our company have spent more than
10 years in beverage
machinery industry,so they have rich experience to provide Turn Key
project Service.
d. There are several engineers available to oversea service. As
long as our customers need them,
they can leave for your country as soon as possible, our principle
to let our production line always runsnormally
Delivery & Packing
Delivery Time: 30-45 days after get your deposit.
Coming Document:
1) Machine Quality Guarantee
2) Complete set install & maintain instruction Book in English
language
3) Complete Document for customer to clear its custom
Packaging Details
The normal package is wooden box(Size: L*W*H). If export to
european countries,the wooden box will be fumigated.If container is
too tigher,we will use pe film for packing or pack it according to
customers special request.
