New Design 5-30HP Water Cooled Chiller For Blowing And Injection
Molding Machine
Product Overview
It has excellent performance of air-cooled chillers, can provide 3
~ 50 °C, especially the low-temperature type machine can make the
water temperature as low as -45°C.(Temperature difference does not
exceed ±1°C).Industrial air-cooled chiller cooling capacity
1316~156245Kcal/h (compressor power 0.5-60HP),Each chiller is
completely assembled in the factory, After pressure, vacuum,
injection of refrigerants, oil injection, testing, inspection
qualified before shipment. The chiller adopts the company's latest
technological achievements: Micro computer control system, Hermetic
compressor, noise control device, Unique melting technology,
Painting process of polyester powder.
Product Parameter
Product Name | Water chiller |
Model | RM-03WCL |
4.4/38℃ Cooling capacity(Kcal/h) | 75800 |
Compressor | All-closed vorticity |
Compressor power(KW) | 2.5 |
Refrigerant | R22 |
Chilled water pump power(KW) | 0.75 |
10℃ Max. flow rate of chilled water(L/min) | 55 |
Water tank capacity(L) | 38 |
Condensing water rate (L/min) | ≥36 |
Weight | 180KG |
Dimension(L*W*H)(mm) | 850*560*870 |
Voltage | 380V-415V/3PHASE/50HZ |
Safety Protection | Water pump interlock protection/leakage protection/overpressure and
anti-phase protection/ refrigerant abnormality protection/
compressor over the temperature protection / and lock of water
protection. |
Product Details& Advantages
1) High quality compressor
As a heart of water-cooling machine, we choose the original
compressor from European and USA with safety production inside, low
noise, energy saving and long life.
2) Evaporator as water tank style
Thick stainless steel Evaporator with automatic water supplying
device, the swell water tank during the installation will be saved,
easy to install and maintain, and also suitable for the case of big
temperature deviations, small flow.
3) High-cooling condenser
High speed punch, reliable turn slice, double turnover, has a
better compact between copper tube and swing slice, imported copper
tube welded with elbow which increase the air sealing, prevent the
leakage of cryogen, especially for the area where lack of water
source and hard water.
4) Machine configuration
Equipped with exact electric temperature controller which control
the water temperature between 3-50℃.inside which there is a
overload protector, high pressure abnormal protector, imported dry
filter and swell valve for stable running and easy repairing and
maintenance.
5) Pump configuration for option
Imported high efficiency pump is available according to customer's
requirement.
6) Multi function operation panel
There are current monitor, compressor on-off switch, pump on-off
switch, electric temperature controller, safety running alert light
on the panel.
